Satellites.xml Update for Enigma2: Full Transponder List & Setup Guide

The Updated satellites.xml File is an essential system file for Enigma2 Linux satellite receivers (Vu+, Dreambox, Octagon, Zgemma, Gigablue). It contains the complete, up-to-date transponder frequency database (Ku-Band, C-Band, and Ka-Band) covering orbital positions from 45.0°E to 30.0°W.

Keeping your satellites.xml file current ensures your receiver accurately detects all active transponders, new channel frequencies, DVB-S2 multi-stream signals, and updated symbol rates during automatic tuner scans.





What's Included in This Update?

• Full Satellite Coverage: Updated transponder parameters for NileSat (7.0°W), Astra (19.2°E), HotBird (13.0°E), Badr/Es'hail (26.0°E), Eutelsat 9B/16A/21B, Hispasat (30.0°W), and Thor (0.8°W).

• Multi-Stream & DVB-S2 Support: Includes updated parameters for MIS (Multi-Stream) transponders, 8PSK/16APSK modulation types, and exact FEC rates.

• Optimized & Clean XML Syntax: Formatted without duplicate entries to speed up manual/automatic satellite search routines and prevent tuner crashes.

• Universal Compatibility: Works across all Enigma2 distributions including OpenATV, OpenPLi, BlackHole, OpenBH, EGAMI, PurE2, VTi, and Dreambox OS.



File Details & System Paths

System Attribute	Details
Filename	satellites.xml
System Path (All Images)	/etc/tuxbox/ (Primary) or /etc/enigma2/
File Permissions	644 (rw-r--r--)



Step-by-Step Installation Guide

1.Download & Unpack File :

Extracts the raw XML database file.

Download the attached archive and extract it on your computer to get the uncompressed satellites.xml file.

2.Transfer via FTP to /etc/tuxbox/ :

Connects to receiver system filesystem.

1. Connect to your receiver using FTP (FileZilla, WinSCP) with your IP address (User: root).

2. Navigate to /etc/tuxbox/.

3. Upload the new satellites.xml file, replacing the existing file.

3.Set File Permissions to 644 :

Ensures correct system access permissions.

Right-click the uploaded satellites.xml in your FTP client, select File Permissions, and set it to 644.

4.Restart Enigma2 GUI & Perform Channel Scan :Reloads transponder tables into memory.

1. On your remote, go to Menu > Standby / Restart > Restart User Interface.

2. After reboot, navigate to Menu > Setup > Service Searching > Automatic Scan (or Manual Scan) to search for channels with updated frequencies.



📥 Downloads & Attachments

• Satellites.xml Package: Satellites.xml-by_update-03-06-2026.zip
